機能別マトリックス（ソレノイドラッチ・ロック） Functional List（Solenoid Latch・Lock）
| 型番 Model No. | TL-258-1 | TL-258-2 | TL-258-1R | TL-258-2R | TL-259-1 | TL-259-2 | TL-259-1R | TL-259-2R | TL-398-1 | TL-398-2 | TL-439 | TL-412 | TL-432 | TL-400 | LD-0039 | LD-0040 | LD-0045 | LD-0043 | LD-0044 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 外観 Appearance |  |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
| サイズ mm Dimension | 31×61×31.5 | 31×61×31.5 | 31×61×31.5 | 31×61×31.5 | 32.5×88×36.5 | 32.5×88×36.5 | 32.5×88×36.5 | 32.5×88×36.5 | 45.5×111.5×46.6 | 45.5×111.5×46.6 | 27×88×32.6 | 20×70.7×29 | 27×95.4×32.6 | 52×92×18 | 53×122×10 | 53×122×10 | 25×83×10 | 72×80×13.1 | 72×80×13.1 | |
| 自重（g） Net Weight | 128.1 | 98.7 | 128.1 | 98.7 | 249.8 | 221.8 | 249.8 | 221.8 | 470 | 440 | 248 | 130 | 252.7 | 218 | 49 | 50 | 38 | 50 | 56 | |
| ソレノイド定格電圧ＤＣ Solenoid Voltage Rating DC | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | 24V | |
|
ソレノイド タイプ Solenoid Type |
連続定格仕様 Continuous Rating Specification | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | - | - | - | - | - |
| 間欠定格仕様 Intermitter Rating Specification | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ● | ● | ● | ● | ● | |
| 消費電力 Consumption Power | 3W | 3W | 3W | 3W | 5W | 5W | 5W | 5W | 7.5W | 7.5W | 5W | 3.8W | 2.67W | 1.9W | 38.4W | 38.4W | 38.4W | 38.4W | 38.4W | |
|
通電時動作
Operation When Energizing |
ラッチ引込型 Latch Pulled in Type | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | - | - | - | - | - | - | - | - |
| ラッチ押出型 Latch Pushing Type | - | - | - | - | - | - | - | - | - | - | - | ● | ● | - | - | - | - | - | - | |
| ラッチ解放型 Latch Cam Type | - | - | - | - | - | - | - | - | - | - | - | - | - | ● | - | - | - | - | - | |
| キーパー蹴出型 Keeper Kicking Out Type | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ● | ● | ● | ● | ● | |
| 引込力 Ｎ（Kgf）※押出力 Retracting Force N (Kgf) ※Pushing Force | 0.98 ～ 6.87 (0.1 ～ 0.7) |
0.98 ～ 6.87 (0.1 ～ 0.7) |
0.98 ～ 6.87 (0.1 ～ 0.7) |
0.98 ～ 6.87 (0.1 ～ 0.7) |
1.96 ～ 15.7 (0.2 ～ 1.6) |
1.96 ～ 15.7 (0.2 ～ 1.6) |
1.96 ～ 15.7 (0.2 ～ 1.6) |
1.96 ～ 15.7 (0.2 ～ 1.6) |
1.8 ～ 23 (0.18 ～ 2.3) |
1.8 ～ 23 (0.18 ～ 2.3) |
3.44以上 (0.35以上) |
※ 0.82以上 (0.08以上) |
※ 0.39以上 (0.04以上) |
- | - | - | - | - | - | |
| 非通電時ラッチ突出長さ mm Emergency Unlocking Mechanism | 10 | 10 | 10 | 10 | 12 | 12 | 12 | 12 | 15 | 15 | 12 | 3 | 5 | - | - | - | - | - | - | |
| ラッチストローク mm Latch Stroke | 3 | 3 | 3 | 3 | 5 | 5 | 5 | 5 | 8 | 8 | 6 | 5 | 6 | - | 10 | 10 | 2 | 9 | 9 | |
| 非常解錠機構 Emergency Unlocking Mechanism | ● | - | ● | - | ● | - | ● | - | ● | - | - | - | - | - | ● | ● | ● | ● | ● | |
| ラッチ可変機構 Latch Variable Mechanism | - | - | - | - | - | - | - | - | ● | ● | - | - | - | - | - | - | - | - | - | |
| マイクロスイッチ Micro Switch | - | - | - | - | - | - | - | - | ● | ● | - | - | - | ● | - | ● | - | ● | ● | |
| ラッチ負荷 Latch Load | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ● | ● | ● | ● | ● | |
| 防滴性能 Rainproof | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ● | - | |
| ダンパー内蔵 Incorporating Damper | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ● | |
